Versatile rotary solution

With the HRTA series, Nanotec offers hollow rotary tables in four sizes. Equipped with a crossed roller bearing, they provide high positioning accuracy, excellent runout characteristics and a max. axial force of 4,000 N.

The combination of a hollow rotary table with a stepper motor results in a rotating actuator that is ideal for mounting positioning tables, end-of-arm-tooling (EOAT) or pick-and-place grippers.

• For stepper motors size NEMA 17, 23/24, 34
• Lifetime of 20,000 h
• Max. gear backlash of 1´
• High efficiency

Maximum performance and flexibility

The intelligent compact drives from Nanotec combine motor, controller and encoder in a space-saving package. With its 80 mm flange and a rated power of up to 942 W, the PD6-EB is the most powerful brushless DC motor of this product family.

• Controlled by fieldbus, clock & direction or analog/digital inputs
• Integrated singleturn absolute encoder, multiturn encoder optional
• Fieldbuses: CANopen, EtherCAT, Modbus RTU, Modbus TCP, Profinet and EtherNet/IP
• Easy to parameterize via USB
• Simple programming with Plug & Drive Studio 3
• Highly profitable through reduced installation time and wiring effort

The PD6-EB is ideally suited for dynamic applications with fast acceleration, such as machine tools, printing heads, or camera positioning systems.

The N6 is a compact high-performance controller/drive for stepper (NEMA 14–34) and BLDC motors (up to NEMA 23), with support for all common industrial fieldbuses. Each version is available in four variants: low or high current, with or without STO*.

With six digital and two analog inputs, three feedback inputs and a brake output, the N6 simplifies integration in demanding automation applications.

Highlights

• Field-oriented control (FOC) for efficient and smooth operation
• Rated current: 6 A; peak current: 6 – 18 A
• Supports Hall sensors, incremental (QEI) and SSI encoders
• Integrated brake chopper
• An external brake resistor can also be connected
• Programming via Plug&Drive Studio
• Parameter setting via EtherCAT, CANopen, EtherNet/IP, Modbus TCP, Modbus RTU (RS485)
• *Safe Torque Off (STO) and UL certification coming soon

The N6 is ideal for various motion control applications with a rated power of up to 300 W, for example packaging machines, laboratory automation, medical systems, SMD assembly lines, and winding equipment.

Ideal for positioning systems and valve control

The LBA60 short-stroke actuator is designed for precise positioning with a max. force of up to 1,500 N. The integrated ball screw extends the motor’s service life – even when run at high speeds and loads. With a nominal voltage of 48 V, this compact linear actuator reaches a top speed of 292 mm/s. The built-in encoder provides accurate position information via incremental signals or SSI interface.

This BLDC actuator is ideal for use in adjustment units for positioning tasks or for controlling valves.

• 60 mm flange
• Stroke length: 55 mm
• Incremental resolution: 4,096 CPR / 16,384 PPR
• SSI resolution: 17 Bit
• Optionally with integrated brake
