Versatile rotary solution

With the HRTA series, Nanotec offers hollow rotary tables in four sizes. Equipped with a crossed roller bearing, they provide high positioning accuracy, excellent runout characteristics and a max. axial force of 4,000 N.

The combination of a hollow rotary table with a stepper motor results in a rotating actuator that is ideal for mounting positioning tables, end-of-arm-tooling (EOAT) or pick-and-place grippers.

• For stepper motors size NEMA 17, 23/24, 34
• Lifetime of 20,000 h
• Max. gear backlash of 1´
• High efficiency

Maximum performance and flexibility

The intelligent compact drives from Nanotec combine motor, controller and encoder in a space-saving package. With its 80 mm flange and a rated power of up to 942 W, the PD6-EB is the most powerful brushless DC motor of this product family.

• Controlled by fieldbus, clock & direction or analog/digital inputs
• Integrated singleturn absolute encoder, multiturn encoder optional
• Fieldbuses: CANopen, EtherCAT, Modbus RTU, Modbus TCP, Profinet and EtherNet/IP
• Easy to parameterize via USB
• Simple programming with Plug & Drive Studio 3
• Highly profitable through reduced installation time and wiring effort

The PD6-EB is ideally suited for dynamic applications with fast acceleration, such as machine tools, printing heads, or camera positioning systems.

The N6 is a compact high-performance controller/drive for stepper (NEMA 14–34) and BLDC motors (up to NEMA 23), with support for all common industrial fieldbuses. Each version is available in four variants: low or high current, with or without STO*.

With six digital and two analog inputs, three feedback inputs and a brake output, the N6 simplifies integration in demanding automation applications.

Highlights

• Field-oriented control (FOC) for efficient and smooth operation
• Rated current: 6 A; peak current: 6 – 18 A
• Supports Hall sensors, incremental (QEI) and SSI encoders
• Integrated brake chopper
• An external brake resistor can also be connected
• Programming via Plug&Drive Studio
• Parameter setting via EtherCAT, CANopen, EtherNet/IP, Modbus TCP, Modbus RTU (RS485)
• *Safe Torque Off (STO) and UL certification coming soon

The N6 is ideal for various motion control applications with a rated power of up to 300 W, for example packaging machines, laboratory automation, medical systems, SMD assembly lines, and winding equipment.

The frameless motor kits of the DKA series provide an efficient solution for compact drive units. The modular design of the frameless BLDC motors, comprising a stator and rotor, reduces space requirements and allows for a maximum level of system integration.

Highlights

• Outer diameter 25 – 115 mm
• High torque up to 7.8 Nm
• Speed up to 10,000 rpm
• Easy cable management

By eliminating the need for couplings and mounting components, these frameless BLDC motors minimize material usage and costs. A wide range of sizes and their high power density ensure optimal adaptation to individual requirements.

Designed for applications where space is limited, frameless BLDC motors are ideal for robotics, medical technology, and other applications that demand both high performance and precision.
