Feature:

• Intel® Celeron® Processor J6412 (Elkhart Lake) 2.0 GHz,
  (up to 2.6 GHz)
• GbE Ethernet ports x 2
• COM port x 4 (RS-232 x 2; RS-232/422/485 x 2)
• Dual-screen HDMI 2.0 output supporting 4K resolution
• USB x 6 (3.2 Gen1 x 4, 2.0 x 2)
• DC 9~36V wide input voltage range
• Support WiFi, 4G LTE wireless data transmission



Novakon’s Fanless Embedded Box PC - NBP series is the ideal choice for industrial edge computing. Powered by Intel® 11th generation Celeron® Elkhart Lake J6412, 12th generation Alder Lake N series N97 quad-core processors, or Core™ i3-N305 8-core processors, NBP series is designed as a high-performance, low-power consumption fanless system. Its aluminum chassis design ensures optimal and stable operation even under harsh industrial environment and heavy computation. In addition, the NBP-01 series is equipped with 4 COM ports for connecting various industrial equipment (including RS-232 x 2 and RS-232/422/485 x 2), 2 sets of GbE Ethernet for high-speed ethernet based communication and the Internet access, and dual-screen HDMI 2.0 output supporting 4K resolution. The system supports wide voltage DC 9~36V input, obtaining CE and FCC international safety certifications to meet the requirements of various industrial environments.

The NBP series is suitable for a wide range of industrial applications such as data acquisition, industrial automation, IIoT (Industrial Internet of Things), smart manufacturing, intelligent energy management, warehouse logistics, and more. These systems offer enhanced efficiency and provide stable control, monitoring, and computing capabilities.

Features:

• ARM 9 (400 MHz)
• 7” TFT 800 x 480, 250 cd/m², 20,000 hours
• 19.2 ~ 28.8V, Isolated Power
• Painted plastic chassis, fan-less design
• Panel or VESA 75mm x 75 mm mount, IP65 front bezel
• ESD Protection : Level 4 (Contact Discharge 8KV, Air-Gap Discharge 15KV), Class A
• Suitable for industrial applications

The N07 is 7” HMI equipped with ARM 9 (400MHz) CPU, 128MB SDRAM, 128MB Flash and rich communication interfaces, including 3 serial ports (RS-232/422/485), USB (host/device), Ethernet port, and SD Card slot for expansion. The system comes with 4 wire resistive touch, IP65 front panel protection against dust and water, and VESA mount or panel mount design.

With iFace Designer, the HMI visualization software, it fulfills all aspects of monitoring and control requirements in factory/process automation, measurement systems, and industrial IoT applications via the database of splendid vector graphics, wide coverage of PLC drivers, diversified smart functions and industrial communication and cloud communication protocols.

Features:

• Intel® Celeron® Processor J6412 (Elkhart Lake) 2.0 GHz (up to 2.6 GHz)
• 21.5” Full HD 1920x1080, TFT-LCD
• Projected Capacitive Touch
• IP66-rated aluminum front bezel and steel chassis
• GbE Ethernet ports x 2
• COM port x 4 (RS-232 x 2, RS-232/422/485 x 2)
• USB x 5 (3.2 Gen1 x 4, 2.0 x 1)
• DC 9~36V wide range power input
• Fan-less, modular detachable design
• VESA mounting 100x100mm / Panel mounting

Novakon Panel PC

Modern industrial design emphasizes usability and flexibility. Industrial panel pc are facing new challenges as they are no longer just functional add-ons. User experience must be friendly, intuitive, and have a highly flexible interface, while also having an advanced appearance.

Novakon's NPP Series provides users with a perfect experience: intelligent, intuitive, and expandable. NPP Series’ Box PC offers a modular design that can be paired with various CPU processors and hardware storage. The screen features narrow bezels with fanless, true-flat touch screen in sizes of 15.6" and 21.5". The 16:9 widescreen display allows for clear visibility of data, and it is designed with IP66 waterproof capabilities.

Feature:

• TI ARM® Cortex™-A8, Sitara™ AM3352 (1GHz)
• 10.2” TFT 800 x 480, 350 cd/m², 20,000 hours
• 19.2 ~ 28.8V, Isolated Power
• Painted plastic chassis, fan-less design
• Panel or VESA 75mm x 75 mm mount, IP65 front bezel
• ESD Protection : Level 4 (Contact Discharge 8KV, Air-Gap Discharge 15KV), Class A
• Suitable for industrial applications



The P10 is 10.2” HMI equipped with ARM Cortex-A8 (1GHz) CPU, 512MB SDRAM, 4GB eMMC, and rich communication interfaces, including 3 serial ports (RS-232/422/485 or CAN bus as option), USB (host/device), Ethernet ports (2nd one as option), SD Card slot for expansion, and WiFi connection via external USB dongle. The system comes with 4 wire resistive touch, IP65 front panel protection against dust and water, and VESA mount or panel mount design.

With iFace Designer, the HMI visualization software, it fulfills all aspects of monitoring and control requirements in factory/process automation, measurement systems, and industrial IoT applications via the database of splendid vector graphics, wide coverage of PLC drivers, diversified smart functions and industrial communication and cloud communication protocols.

Feature:

• Intel® Celeron® Processor J6412 (Elkhart Lake) 2.0 GHz,
  (up to 2.6 GHz)
• GbE Ethernet ports x 2
• COM port x 4 (RS-232 x 2; RS-232/422/485 x 2)
• Dual-screen HDMI 2.0 output supporting 4K resolution
• USB x 6 (3.2 Gen1 x 4, 2.0 x 2)
• DC 9~36V wide input voltage range
• Support WiFi, 4G LTE wireless data transmission



Novakon’s Fanless Embedded Box PC - NBP series is the ideal choice for industrial edge computing. Powered by Intel® 11th generation Celeron® Elkhart Lake J6412, 12th generation Alder Lake N series N97 quad-core processors, or Core™ i3-N305 8-core processors, NBP series is designed as a high-performance, low-power consumption fanless system. Its aluminum chassis design ensures optimal and stable operation even under harsh industrial environment and heavy computation. In addition, the NBP-01 series is equipped with 4 COM ports for connecting various industrial equipment (including RS-232 x 2 and RS-232/422/485 x 2), 2 sets of GbE Ethernet for high-speed ethernet based communication and the Internet access, and dual-screen HDMI 2.0 output supporting 4K resolution. The system supports wide voltage DC 9~36V input, obtaining CE and FCC international safety certifications to meet the requirements of various industrial environments.

The NBP series is suitable for a wide range of industrial applications such as data acquisition, industrial automation, IIoT (Industrial Internet of Things), smart manufacturing, intelligent energy management, warehouse logistics, and more. These systems offer enhanced efficiency and provide stable control, monitoring, and computing capabilities.

Features:

• ARM 9 (400 MHz)
• 7” TFT 800 x 480, 250 cd/m², 20,000 hours
• 19.2 ~ 28.8V, Isolated Power
• Painted plastic chassis, fan-less design
• Panel or VESA 75mm x 75 mm mount, IP65 front bezel
• ESD Protection : Level 4 (Contact Discharge 8KV, Air-Gap Discharge 15KV), Class A
• Suitable for industrial applications

The N07 is 7” HMI equipped with ARM 9 (400MHz) CPU, 128MB SDRAM, 128MB Flash and rich communication interfaces, including 3 serial ports (RS-232/422/485), USB (host/device), Ethernet port, and SD Card slot for expansion. The system comes with 4 wire resistive touch, IP65 front panel protection against dust and water, and VESA mount or panel mount design.

With iFace Designer, the HMI visualization software, it fulfills all aspects of monitoring and control requirements in factory/process automation, measurement systems, and industrial IoT applications via the database of splendid vector graphics, wide coverage of PLC drivers, diversified smart functions and industrial communication and cloud communication protocols.

Features:

• Intel® Celeron® Processor J6412 (Elkhart Lake) 2.0 GHz (up to 2.6 GHz)
• 21.5” Full HD 1920x1080, TFT-LCD
• Projected Capacitive Touch
• IP66-rated aluminum front bezel and steel chassis
• GbE Ethernet ports x 2
• COM port x 4 (RS-232 x 2, RS-232/422/485 x 2)
• USB x 5 (3.2 Gen1 x 4, 2.0 x 1)
• DC 9~36V wide range power input
• Fan-less, modular detachable design
• VESA mounting 100x100mm / Panel mounting

Novakon Panel PC

Modern industrial design emphasizes usability and flexibility. Industrial panel pc are facing new challenges as they are no longer just functional add-ons. User experience must be friendly, intuitive, and have a highly flexible interface, while also having an advanced appearance.

Novakon's NPP Series provides users with a perfect experience: intelligent, intuitive, and expandable. NPP Series’ Box PC offers a modular design that can be paired with various CPU processors and hardware storage. The screen features narrow bezels with fanless, true-flat touch screen in sizes of 15.6" and 21.5". The 16:9 widescreen display allows for clear visibility of data, and it is designed with IP66 waterproof capabilities.
