HEATING BETTER WITH LOOP

The STEGO Thermal Management experts use the advantages of the elastic and at the same time firm connection capabilities of the Loop profile to improve the very own task of our enclosure heaters: heating. After all, our customers are experts who require reliable thermal management that functions under all circumstances.

Compact heater for the protection of electrical and electronic components in enclosures. Its design ensures great convection resulting in excellent heat dissipation. A touch-safe plastic cover provides for low surface temperatures on the side of the device. The practical push-in clamping terminal enables quick and easy electrical connection.

• Clip fixing and pressure clamp for quick mounting
• Low surface temperature
• Earthed plastic casing
• Wide voltage range
• Heater body in loop design for optimal temperature distribution
• Shock and vibration proof

Smart Sensor for Monitoring Temperature and Humidity

Condition monitoring is an essential part of predictive maintenance. STEGO's Smart Sensor CSS 014 measures two important parameters - temperature and humidity - and helps to maintain an optimal climate within switch cabinets. The CSS 014 measures ambient temperatures with high sensitivity within a range of -40 to +60 °C while keeping a close eye on the relative humidity range from 0 to 100% RH.

The CSS 014 Smart Sensor transmits the data it acquires as a standardized analog 4-20 mA signal. This signal users can further process and convert the measured values within a control or monitoring unit, e.g. a PLC. Due to high measuring accuracy and signal strength connection wires with a maximum length of 30 m can be used.

The sensor unit of the CSS 014 is thermally decoupled and encapsulated with a circumferential seal. A shielded M12 round plug ensures a fast connection and safely transmits the signals of the two measuring channels for processing. The operating voltage is DC 24 V (DC 12 - 30 V) with a maximum power consumption of 1.8 W (typically 0.4 W). Tested safety is certified for the Smart Sensor CSS 014 through successful approvals with VDE and UL according to the standard IEC 61010-1 / DIN EN 61010-1.

Higher airflow in enclosures

Filter fans are used to provide an optimum climate in enclosures and cabinets with electrical/electronic components. The interior temperature of an enclosure can be reduced by channelling cooler filtered outside air into the enclosure thus expelling heated internal air. The resulting airflow prevents formation of localised hot pockets in installations and protects electronic components from overheating.

The Filter Fan Plus series uses a new airflap-outlet technology for the air outlet and thus reaches a high degree of airflow. A ratchet mechanism is used for mounting and provides high stability and tightness. Depending on the application there are two systems that are available - the FPI or FPO system. The FPI system is a standard installation with a filter fan in the lower part of the enclosure which ensures that fresh air is fed into the enclosure (airflow direction "In"). This system consists of a filter fan and exit filter. Whereas in the FPO system, the filter fan is located in the upper area of the enclosure to avoid heat buildups (airflow direction "Out"). The FPO system is composed of an intake filter and exit filter fan. The Filter Fan Plus series may also be used outdoors with appropriate protective measures or when equipped with weather proof accessories, e.g. Hose-proof Hood FFH 086.

The Smart Sensor Current ESS 076 measures the AC current of the conducted lines without contact. Acquired measurement data is output analog (4-20 mA signal) or digital (IO-Link). Measured and processed data- such as power and energy - are provided via the IO-Link interface to higher-level systems such as machine controllers or edge computers for condition monitoring. The ESS 076 is ideal for the permanent collection of load profiles from plants and machines. These help in applications such as peak load detection to achieve savings in energy costs.

• Measures AC current up to 100 contactless
• Cable diameter up to 11.4 mm
• Internal processing of measured values
• Analog & digital interface in one device

ENERGY EFFICIENCY AND SUSTAINABILITY

Monitoring power consumption plays a crucial role in identifying inefficient operating conditions and preventing energy waste in industrial applications. The ESS 076 provides precise measurement of current consumption up to 100 A on wires up to 11.4 mm in diameter.

With an analogue and digital interface for seamless integration, this innovative sensor offers the ability to collect energy efficiency data and precisely monitor energy consumption. The ESS 076, with its high-precision measurement technology, makes it possible to effectively manage energy costs, sustainably reduce operating costs and make informed decisions for energy efficiency projects or capacity expansions.
