The wireless panel series HGW offers highest flexibility in monitoring and controlling production processes. The mobile handheld panels are available in different versions – with or without Safety and rotary encoder or in portrait and landscape format.

• Mobile, wireless operating panel with data transfer via WLAN
• Wireless Safety functions - SIL 3, PL e
• High-performance EDGE2 Technology processor, OPC UA communication
• 10.1" WXGA color display, multi-touch (projective capacitive), 800 x 1280 pixels
• Battery pack integrated: 2 hours continuous-load operation without recharging
• 1,350 g including battery pack and Safety elements

Safety Functions via WLAN

In addition to function-oriented data, Safety data from emergency stop and confirmation buttons, as well as key switch can be sent wirelessly with the HGW panel 1033-3 and the HGW 1033-32. Safety-relevant data is transmitted via the standard WLAN using the Black Channel principle. The Safety panels are TÜV-certifiied and with SIL 3, PL e, meet the highest requirements.

Whether for classic operating or modern visualization concepts – with the HMIs from SIGMATEK, your machines cut a good figure in any situation. Our human-machine interfaces are compactly designed and fanless. You have the choice between panels with a processor and remote operating units without a processor (HMI-Link up to 100 m).

Regardless of whether single- or multi-touch screens – we put the main focus on all our human-machine interfaces to ensure that you can work intuitively, quickly and safely.

For demanding visualizations (HTML5), our HMIs with EDGE3 Technology processors are the best choice. All HMIs equipped with a processor are fit for the Smart Factory (OPC UA communication).

The broad selection includes color touch displays from 3.5 to 23.8 inches - with single or Multitouch (PCT). In addition to the classic 4:3 format, panels in vertical and widescreen format are available. Customer-specific HMI designs are also possible.

• Open: with standard interfaces such as Ethernet, CAN, USB, HMI-Link, VARAN or RS232, the HMIs easily connect
• Fast and reliable: data exchange with the control and additional components
• Fit for the digital factory: all SIGMATEK HMIs with a processor support OPC UA communication
• Comfortable: simply create visualizations with the HMI-tools LASAL SCREEN and the web-based LASAL VISUDesigner

The Safety technology is a component of all SIGMATEK's complete automation systems. All Safety modules, such as S-DIAS Safety controllers and I/Os, as well as drives with Safety functions are seamlessly integrated into the entire system.

• Modular Safety components for individual Safety requirements
• Simple engineering: LASAL SAFETYDesigner with many ready-to-use Safety software function blocks
• One bus system for standard and Safety

Safety System S-DIAS

S-DIAS Safety is a part of the modular S-DIAS control and I/O system (IP20). The Safety solution for the DIN rail consists of a Safety controller (SCP) and safe I/O modules. The transmission of Safety-relevant data is based on the Black Channel principle – by cable or wireless.
The TÜV-certified Safety system can also be used as a stand-alone solution. Existing machines and equipment can therefore be gradually equipped with Safety functions.

• Modern: designed for the highest Safety requirements – SIL 3/PL e, Cat.4
• Compact: module dimensions of only 12.5 x 104 x 72 mm (W x H x D) - Safety PLC and I/Os
• Flexible: customized macro libraries and parameter lists Hot-Swap feature
• Efficient: individual adaptation to requirements through modular configuration
• Easy: minimal wiring and comfortable engineering with LASAL SAFETYDesigner

The new SCP 211 safety CPU from SIGMATEK impresses with its fast processing speed and extensive memory. On the software side, it is now possible to create customized macro libraries and parameter lists for safety applications. This reduces the engineering effort enormously. In the LASAL SAFTEYDesigner, it is only necessary to create one safety application for a machine or system with numerous options, which applies to all equipment variants.

The modularDIAS Drive generation MDD 2000 combines high performance and flexibility to control servo motors.

• Highest power density in a highly compact design with up to three axes, a supply, power filter, brake resistor, DC-Link circuit and an overload factor of up to 300 percent
• Modular use as standalone or in combination with any number of axis modules enables a precisely fitting drive concept
• Many Safety functions: Safe Torque Off (STO), Safe Stop 1 + 2 (SS1 + SS2), Safe Operating Stop (SOS), Safe Brake Control (SBC), Safe Brake Test (SBT), Safely-Limited Speed (SLS), Safe Speed Monitor (SPM), Safe Maximum Speed (SMS), Safe Maximum Acceleration (SMA), Safely Limited Acceleration (SLA), Safely Limited Position (SLP), Safe Position (SP), Safely Limited Increment (SLI), Safe CAM (SCA), Safe Direction (SDI) - all according to SIL 3, PL e, Cat. 4 and TÜV certified!
• Safety Functionblocks (when using a Safety-CPU SCP 211): DH-Transformation, Collision Detection, Safe Area
• Shortened installation thanks to clever connection mechanism in fast, tool-free stacking technology
• In addition to digital motor feedback interface Hiperface DSL, numerous encoder variants are supported

Dimensions:
DIAS Drive size 1: 75 x 240 x 219 mm (W x H x D)
DIAS Drive size 2: 150 x 240 x 219 mm (W x H x D)
