Helical gearboxes and helical geared motors

Our bevel helical gearbox is designed as a compact drive unit for highly dynamic applications. The requirements for operation with servo motors have been implemented accordingly. During development, attention was also paid to high operational reliability through amply dimensioned bearing points and gearing design. Furthermore, the housing with an integrated square flange on the output side offers maximum rigidity and can be installed or attached universally thanks to the symmetrical inline housing. The drive is available with a solid or hollow shaft (possibly with an optional clamping set).

The output shafts can also be made of stainless steel. A stainless steel housing (stainless steel gear, hygienic drive, wash-down application) is available for particularly high demands on the surface quality.

Requirements placed on new transmission concepts were taken into account. Minimum torsional backlash, high rigidity, low overall weight, high efficiency, maximum flexibility in connection with a universal installation position are features that enable the drive to be used successfully.

Characteristics

• High efficiency > 90%
• Flexible mounting with interchangeable flange system
• Torsion-resistant servo motor coupling as the optimal connection between the servo motor and the gearbox
• External stainless steel screws for better cleaning properties
• High housing rigidity for robust and tough applications
• Smooth housing surface (hygienic drive, wash-down drive)
• Square flange for universal mounting options
• Hollow shaft design as the optimal interface for the relevant application
• Symmetrical in-line housing design allows mounting in all positions+
• Maintenance-free lifetime lubrication

Options

• Stainless steel hood to cover the hollow shaft
• Hollow shaft design with shrink disk
• Version with solid shaft
• Stainless steel version (stainless steel gear, hygienic drive)

Areas of application

• packaging machines
• machine tools
• storage technology
• robotics
• beverage industry
• food industry

Our worm gears and helical worm gears / motors are high-performance gears with a very high degree of efficiency. All worm shafts are made from case hardened alloy steel and the flanks are precision ground. The worm wheels are made from centrifugally cast bronze. Helical worm gears are equipped with a helical gear. Worm gears with shrink disc, torque limiter, as well as adjustable backlash designs are also part of our standard product range.

Our worm gearboxes and helical worm gearboxes type S and SS are high-Performance gearboxes in universal design. The housings are made from high quality cast iron. The rugget walls and inner ribbing ensure extremely torsional stiff and noise dampening housings. The external ripping provides a rapid heat dissipation.

Characteristics

• Optimised size/performance ratio
• Designed for permanent operation under rough circumstances
• Extreme torsional resistance and low noise
• Housing produced from high quality grey cast iron with rugged walls and internal ribbing
• Case hardened worm shafts and worms with precision ground flanks
• Worm wheels produced from centrifugally cast bronze
• Space saving angular drive
• Helical worm gearboxes equipped with helical gear wheel

Options

• Basic mounting, flange mounting or universal design
• Output shaft available as solid shaft or hollow shaft
• Shrink disc, torque limiter, as well as adjustable backlash
• Second shaft end for fitting encoders or brakes
• Torque arm
• IEC standard motor mounting
• Free input shaft
• ATEX specification

Areas of application

• Filling systems
• Chemical industry
• Construction machinery
• Assembly technology
• Textile machines
• Machine tools

Our stainless steel gearboxes (SMN) offer an optimal solution for all applications in which cleanliness, hygiene and increased demands on material quality are important. Dirt cannot deposit on the absolutely smooth surface. These drives Show a very high resistance against aggressive substances as well.

Our stainless steel gearboxes (SMN) can be combined with our stainless steel motors (SBH, SBE, and N).

Our worm gear (also with motor) is also available in aluminium with a special coating.

Characteristics

• Robust and compact
• Lubricant suitable for the food industry (NFS H1 authorized)
• Housing made of 1,4308 stainless steel
• Shaft made of 1,4301stainless steel
• Independent of mounting positions
• can be combined with our Stainless steel motors
• IEC standard motor attachment or direct attachment

Options

• Output shaft as a solid shaft
• Flange version
• Stainless steel Motor made of 1.4301 stainless steel
• customized solutions possible

Areas of application

• Food industry
• Beverage industry
• Pharmaceutical technology
• Chemical industry
• Environmental engineering
• Packaging machines

Our bevel helical gearbox is designed as a compact drive unit for highly dynamic applications. The requirements for operation with servo motors have been implemented accordingly. During development, attention was also paid to high operational reliability through amply dimensioned bearing points and gearing design. Furthermore, the housing with an integrated square flange on the output side offers maximum rigidity and can be installed or attached universally thanks to the symmetrical inline housing. The drive is available with a solid or hollow shaft (possibly with an optional clamping set).

The output shafts can also be made of stainless steel. A stainless steel housing (stainless steel gear, hygienic drive, wash-down application) is available for particularly high demands on the surface quality.

Requirements placed on new transmission concepts were taken into account. Minimum torsional backlash, high rigidity, low overall weight, high efficiency, maximum flexibility in connection with a universal installation position are features that enable the drive to be used successfully.

Characteristics

• High efficiency > 90%
• Flexible mounting with interchangeable flange system
• Torsion-resistant servo motor coupling as the optimal connection between the servo motor and the gearbox
• External stainless steel screws for better cleaning properties
• High housing rigidity for robust and tough applications
• Smooth housing surface (hygienic drive, wash-down drive)
• Square flange for universal mounting options
• Hollow shaft design as the optimal interface for the relevant application
• Symmetrical in-line housing design allows mounting in all positions+
• Maintenance-free lifetime lubrication

Options

• Stainless steel hood to cover the hollow shaft
• Hollow shaft design with shrink disk
• Version with solid shaft
• Stainless steel version (stainless steel gear, hygienic drive)

Areas of application

• packaging machines
• machine tools
• storage technology
• robotics
• beverage industry
• food industry

Our worm gears and helical worm gears / motors are high-performance gears with a very high degree of efficiency. All worm shafts are made from case hardened alloy steel and the flanks are precision ground. The worm wheels are made from centrifugally cast bronze. Helical worm gears are equipped with a helical gear. Worm gears with shrink disc, torque limiter, as well as adjustable backlash designs are also part of our standard product range.

Our worm gearboxes and helical worm gearboxes type S and SS are high-Performance gearboxes in universal design. The housings are made from high quality cast iron. The rugget walls and inner ribbing ensure extremely torsional stiff and noise dampening housings. The external ripping provides a rapid heat dissipation.

Characteristics

• Optimised size/performance ratio
• Designed for permanent operation under rough circumstances
• Extreme torsional resistance and low noise
• Housing produced from high quality grey cast iron with rugged walls and internal ribbing
• Case hardened worm shafts and worms with precision ground flanks
• Worm wheels produced from centrifugally cast bronze
• Space saving angular drive
• Helical worm gearboxes equipped with helical gear wheel

Options

• Basic mounting, flange mounting or universal design
• Output shaft available as solid shaft or hollow shaft
• Shrink disc, torque limiter, as well as adjustable backlash
• Second shaft end for fitting encoders or brakes
• Torque arm
• IEC standard motor mounting
• Free input shaft
• ATEX specification

Areas of application

• Filling systems
• Chemical industry
• Construction machinery
• Assembly technology
• Textile machines
• Machine tools
