iC-PZ Series High-Resolution Reflective Absolute Encoder
Description
The iC-PZ is a complete lensless optical reflective absolute encoder IC. With its integrated blue LED and interpolator, the iC-PZ provides
a high-resolution single-chip absolute linear or rotary encoder solution. Independently configurable BiSS/SSI, ABZ, UVW, SPI, and analog Sin/Cos outputs may be used singly or in combination to provide a highly flexible system. FlexCount® and FlexCode® allow arbitrary ABZ resolution and arbitrary code disc diameter.
Automatic calibration corrects for sin/cos signal errors (offset, gain, and phase) and code wheel eccentricity without requiring external hardware or software. Calibrated parameter values are stored in an external EEPROM. Wide assembly tolerances ensure that the iC-PZ is easy to install and align, making design-in to any application simple.
Reflective, compact, high-resolution, absolute encoder iC
• iC-PZ0974 and iC-PZ2656 for reflective code discs up to ø45 mm
• iC-PZ205 for reflective code discs > ø45 mm and linear scales
(max. 6.71m)
• Miniature oQFN32 5×5 package
• Monolithic HD Phased Array with excellent signal matching
• System-on-chip design with embedded blue LED for excellent reliability, EncoderBlue®
• FlexCount® interpolation for arbitrary ABZ resolutions
• FlexCode® circuitry for arbitrary code disc diameters
• UVW commutation signals with 1 to 32 CPR, for motors of up
to 32 pole pairs
• LED power control for constant illumination
(sine square or sum control)
• Absolute singleturn resolution of 22 bits (ø26 mm) via built-in interpolation
• On-chip automatic signal adjustment
• Calibration and configuration storage via external I²C EEPROM
• Digital BiSS, SSI, and SPI interfaces with CMOS I/O
• Temperature detection and monitoring
• 2.5, 3.3, and 5.0 V compatible I/O ports
• Configurable analog outputs
• Absolute data interface for connection of external multiturn sensors
