This series of optical encoder iCs features monolithically integrated photosensors. Precision sine/cosine signals are output for a high-resolution interpolation by subsequent devices, such as iC-MNF, resolving a singleturn position with 23 bits and higher. Output amplitudes of several hundred millivolts are achieved at low illumination levels, saving LED current for durability. As a typical Nonius scale for iC-PNE repeats 8 times per turn, 4 sector tracks are scanned digitally by additional photosensors. This section runs independently on a lower supply voltage with extremely low power consumption, allowing battery operation. The typical application of iC-PNE devices are absolute position encoders for motion control and drive applications.

Features:

• For compact, high resolution absolute position encoders
• Monolithic 3-channel HD phased array with excellent signal matching
• Embedded octal sector detection by 4-bit Gray code scanning
• Moderate track pitch for reduced crosstalk
• Ultra-low dark currents for operation at high temperatures
• Low-noise photocurrent amplifiers with 1 MΩ transimpedance gain
• Enhanced EMI tolerance by low impedance differential, short-circuit-proof, analog sine/cosine outputs
• Operation from 4.1 V up, respectively 1.8 V for digital section
• Operational temperature range of -40 to +125 °C
• Space-saving, RoHS compliant optoQFN package
• Sampling with evaluation kit and code disc
