Cable carrier UNIFLEX Advanced 1775
Our successful cable carrier in new size – more height, more width – simply more space for medium and large cable packages.

In addition to more generous dimensions, the UA1775 convinces with its particularly smooth running and its long service life. The low-distortion design ensures for stable chain bodies and thus less wear.

A bonus for the environment: we manufacture this cable carrier with up to 35% of regrind!

Proven and popular - the well-known quick-opening system. No need to say that we have retained this feature for the new size. It allows quick, easy and time-saving cable laying. Merely two movements and a screwdriver – that is all you need. Particularly convenient: Even when open, the crossbar remains attached to the chain link. And if necessary, it can easily be removed by unscrewing.

The UA1755 can be ordered by meter ex stock or as ready-to-install system. Upon request, our competent service team carries out the professional installation. Furthermore, the matching guide channel can be ordered right away. It is optionally made of aluminium (TKAL) or steel/stainless steel (TKSG).

• Use of up to 35% pure regrind
• Rear grips at stopper system for better force transmission and higher strengths
• Closed design with inside and outside opening crossbars and with integrated damping system
• Glide shoes available for all types (first time!)
• UMB connectors made of particularly resilient plastic with strength similar to aluminium for directly screwing without metal insert
• Integrable strain relief for cable ties or LineFix clamps
• Fixable and movable dividers and height subdivisions available
• Lateral integration of adapter plate for mounting additional attachment parts
• Application in 90° rotation and circular arrangements possible due to lateral wear surfaces
• KR/RKR Applications upon request
• Approved standardized GO module with glide-optimized chain links

Pitch 77.5 mm
Inner height 56 mm
Inner widths 100 – 250 mm
Bending radii 90 – 340 mm

TRAXLINE® cables for cable carriers: Reliable, robust with high availability. Your benefit from many years of experience combined with ongoing optimization, proven in tests and applications. TRAXLINE® cables stand for competent system-supply with worldwide on-site service.

Our Series are available in different qualities:

• 200/200C: Layer stranded cables with PVC outer jacket for light to medium demands
• 400/400C: Bundle stranded cables with PVC outer jacket for medium heavy demands
• 700/700C: Bundle stranded cables with PUR outer jacket for heavy demands
• 1000/1000C: Bundle stranded cables with TPE outer jacket for really heavy loads

Our portfolio includes:

• Control Cables
• Power Cables
• Data Cables
• BUS Cables
• Coaxial Cables
• Fiber Optic Cables
• High Voltage Cables
• OEM Cables
• TRAXLINE® pre-assembled OEM high flex cables

Protecting cables effectively: The optimized cover construction of the UAT1555 provides outstanding protection against penetration of dirt and chips into the carrier interior.

The UAT1555 cable carrier provides outstanding protection for the routed cables and hoses. It has been developed for harsh environmental conditions with chips, dirt and dust and effectively prevents foreign bodies from entering the cable space.

The optimized geometry of the chain links makes the carrier very stable, with a large unsupported length. The integrated damping system makes it very quiet.

The carrier series is not just remarkable for its technical attributes, but also for its visual design, with its impressive style and functionality. For example, the almost completely smooth side band contour of the individual chain links presents hardly any gap through which foreign bodies could penetrate.

With the UMB connectors you can connect the UAT1555 easily from above, from below or at the front. The optional C-rails and LineFix saddle-type clamps allow the cables to be fixed securely and simply. C-rails and strain relief combs are fixed with the UMB connectors and do not have to be screwed separately.

• Outstanding protection for the cables
• Quick cable laying – outside opening variant
• Large unsupported length
• For unsupported and gliding arrangements
• Cover system also on the connection
• Simply unlock cover with a screwdriver
• Connectors with optional strain relief comb – also double
• Gentle on the cables – interior space without interfering edges
• Dividers and height separations for cable subdivision

Pitch 55.5 mm
Inner height 50 mm
Inner widths 75 - 175 mm
Bending radii 100 - 300

TKHP SERIES “THE GRIZZLY”

High-Performance cable carriers for long travel lengths and high additional loads

Our new TKHP series is a reliable and efficient cable routing for high-performance applications with travel lengths up to 1.500 meters in rough conditions, such as port cranes or the transport of bulk materials. It can absorb a high level of force, is highly durable and dirt-resistant.

Features

• Massive, enclosed, stain-repellend stop system
• Massive sidebands through robust double ­fork-bracket-construction
• Sidebands easy to assemble
• Reinforced symmetrically arranged pin bore connection for better force transmission
• Integrated noise damping
• Quick and easy opening to the inside or outside for cable laying
• Soil-resistant outer contour
• Easy change of components
• Maintenance-free
• Linear force curve in the sideband
• Quiet and low-wear operating through polygon-­optimized contour and radii
• Reduce drive power through less friction
