Pendant station for auxiliary control with modern ergonomic shape, easy to handle, user friendly and sturdy.
Mike is the result of careful analysis of ergonomic aspects and it is rich in high-performing features to meet the most demanding requirements.

FEATURES

• Reduced installation and wiring time and costs: the cable inlet and the switches fitted in the base of the control station are separated from the actuators, mounted on the cover.
• Innovative suspension system with concealed cables to enable rapid, correct, ergonomic installation.
• Rubber pushbuttons with symbol disks to ensure protection against dust and prevent jamming when the control station is used in harsh environments.
• The emergency stop mushroom pushbutton complies with standard ISO 13850.
• Positive opening NC contacts for safety functions.
• Mechanical life of pushbuttons and switches: 10 million operations.
• IP protection degree: Mike is classified IP 65, IP 66, IP 67 and IP 69K.
• IK protection degree: Mike is classified IK 08.
• NEMA protection degree: Mike is classified Type 1, 4 and 4X.
• Extreme temperature resistance: -40°C to +80°C.
• All materials and components used are wear resistant and guarantee protection of the unit against water and dust.

OPTIONS

• Available in configurations with 4 to 15 actuators.
• Available with specific protection for actuators mounted on the bottom of the control station.
• 1NO or 1NC switches, LEDs voltage 24/48 Vac/dc or 110/230 Vac and 110 Vdc, and potentiometers.
• Mechanical interlock to prevent simultaneous operation of opposite functions.
• Wide range of actuators in different colours: one or two speed pushbuttons, selector switches and key-selector
switches in various operation configurations, pilot lights, impulse or latched mushroom pushbuttons with rotation or key-operated release.
• One speed pushbuttons and selector switches available in illuminated version in a range of colours.
• Latched on-off maintained pushbutton to give an effective visual perception of the activated function.
• Available with labels (symbols and lettering) to be applied next to the actuators or with pushbuttons with two-colour moulded permanent symbols.

CERTIFICATIONS

• CE marking and cULus* marking.
• Mike is available, upon request, with the SIL1 certification (Safety Integrity Level 1), according to Standard IEC 61508.
• Complying with accident prevention regulation BGV C 1 (only for Germany).

Sturdy, quality, and reliable warning lights featuring a high degree of customization.
They are used in many industrial and automotive markets

FEATURES

• Suitable for many industrial and automotive markets.
• IP protection degree: they are classified IP 65.
• Bodies made of ABS providing great resistance to impacts and vibrations.
• Featuring polycarbonate lenses for a better and powerful light transmission and diffusion.
• Extreme temperature resistance: -20°C to +50°C.
• All materials and components used are wear resistant and guarantee protection of the unit against water and dust.

OPTIONS

• High degree of customization and different solutions available for each kind of market: stack lights, signal beacons, warning horns, RGB warning lights, LED warning horns, electronic sirens, obstruction lights and heavy-duty warning lights.
• Available with SMD or POWER LEDs for a long-lasting light quality.

PRODUCT FAMILIES

• Stack lights.
• Modular stack lights.
• Multicolour RGB warning lights.
• Universal signal beacons.
• LED warning horns.
• Beacon horns.
• Electronic sirens.
• Obstruction lights.
• Heavy duty warning lights.
• Crane & forklift safety lights.
• Machine tool lights.
• Motor and alarm sirens.

• Industrial signal lights.

CERTIFICATIONS

• CE marking and EAC certification.
• RoHS and E37* homolagation.

New position limit switch designed to control the movement of overhead travelling cranes, hoists and machine tools. Sturdy and reliable, Arke is particularly suitable for use in harsh operating conditions.

FEATURES

• Designed to guarantee excellent performance in the most challenging operating conditions.
• 2 fixing holes.
• Positive opening NC contacts for safety functions.
• Mechanical life of switches: 2 million operations.
• IP protection degree: Arke is classified IP65 / IP66 / IP67 with dedicated cable gland M20.
• NEMA protection degree: Arke is classified Type 1.
• Extreme temperature resistance: -53°C to +80°C.
• Aluminium rods with 6x8 mm section, enclosure and head in
thermoplastic material.
• All materials and components used are wear resistant and
guarantee protection of the unit against water and dust.

OPTIONS

• Cross rods with 4 maintained positions every 90°, cross or T rods with 3 maintained position every 90°, single rod or rod with roller with 65° spring return movements.
• 2 slow action switches with 1NC+1NC staggered contacts,
2 slow action switches with 1NO+1NC contacts, or snap action switches with 1NC+1NC contacts
• 3 outputs for cable glands to reduce installation time and make wiring easier.

CERTIFICATIONS
• CE marking, UKCA marking and cULus marking

Slip ring collectors designed to transfer AC/DC current from a fixed supply point to a rotating structure,
transmitting power and control signals, both analogue and digital, to mobile units.
Thanks to the high degree of customization, they are used in a variety of industrial sectors, on cranes, rides, packaging plants.

FEATURES
• Suitable for data and control applications.
• They support the major high speed data transmission and industrial bus system protocols.
• High quality materials and components guarantee reliability
and durability.
• IP protection degree: Pegasus are classified up to max. IP 65.

OPTIONS
• High degree of customization thanks to a fully modular construction system.
• Different assemblies available for low voltage.
• On request, they can be equipped with hydraulic couplings.

CERTIFICATIONS
• CE marking.
