Pendant station for auxiliary control with modern ergonomic shape, easy to handle, user friendly and sturdy.
Mike is the result of careful analysis of ergonomic aspects and it is rich in high-performing features to meet the most demanding requirements.

FEATURES

• Reduced installation and wiring time and costs: the cable inlet and the switches fitted in the base of the control station are separated from the actuators, mounted on the cover.
• Innovative suspension system with concealed cables to enable rapid, correct, ergonomic installation.
• Rubber pushbuttons with symbol disks to ensure protection against dust and prevent jamming when the control station is used in harsh environments.
• The emergency stop mushroom pushbutton complies with standard ISO 13850.
• Positive opening NC contacts for safety functions.
• Mechanical life of pushbuttons and switches: 10 million operations.
• IP protection degree: Mike is classified IP 65, IP 66, IP 67 and IP 69K.
• IK protection degree: Mike is classified IK 08.
• NEMA protection degree: Mike is classified Type 1, 4 and 4X.
• Extreme temperature resistance: -40°C to +80°C.
• All materials and components used are wear resistant and guarantee protection of the unit against water and dust.

OPTIONS

• Available in configurations with 4 to 15 actuators.
• Available with specific protection for actuators mounted on the bottom of the control station.
• 1NO or 1NC switches, LEDs voltage 24/48 Vac/dc or 110/230 Vac and 110 Vdc, and potentiometers.
• Mechanical interlock to prevent simultaneous operation of opposite functions.
• Wide range of actuators in different colours: one or two speed pushbuttons, selector switches and key-selector
switches in various operation configurations, pilot lights, impulse or latched mushroom pushbuttons with rotation or key-operated release.
• One speed pushbuttons and selector switches available in illuminated version in a range of colours.
• Latched on-off maintained pushbutton to give an effective visual perception of the activated function.
• Available with labels (symbols and lettering) to be applied next to the actuators or with pushbuttons with two-colour moulded permanent symbols.

CERTIFICATIONS

• CE marking and cULus* marking.
• Mike is available, upon request, with the SIL1 certification (Safety Integrity Level 1), according to Standard IEC 61508.
• Complying with accident prevention regulation BGV C 1 (only for Germany).

New position limit switch designed to control the movement of overhead travelling cranes, hoists and machine tools. Sturdy and reliable, Arke is particularly suitable for use in harsh operating conditions.

FEATURES

• Designed to guarantee excellent performance in the most challenging operating conditions.
• 2 fixing holes.
• Positive opening NC contacts for safety functions.
• Mechanical life of switches: 2 million operations.
• IP protection degree: Arke is classified IP65 / IP66 / IP67 with dedicated cable gland M20.
• NEMA protection degree: Arke is classified Type 1.
• Extreme temperature resistance: -53°C to +80°C.
• Aluminium rods with 6x8 mm section, enclosure and head in
thermoplastic material.
• All materials and components used are wear resistant and
guarantee protection of the unit against water and dust.

OPTIONS

• Cross rods with 4 maintained positions every 90°, cross or T rods with 3 maintained position every 90°, single rod or rod with roller with 65° spring return movements.
• 2 slow action switches with 1NC+1NC staggered contacts,
2 slow action switches with 1NO+1NC contacts, or snap action switches with 1NC+1NC contacts
• 3 outputs for cable glands to reduce installation time and make wiring easier.

CERTIFICATIONS
• CE marking, UKCA marking and cULus marking

FEATURES

• It consists of a gear motor that transfers movement to the cams and to the other movement detection devices through a primary input reduction stage (worm gear and helical
toothed gear) and one or more secondary output stages (pairs of straight toothed gears).
• Accurate adjustment of cams by means of screws.
• Positive opening NC contacts for safety functions.
• Mechanical life of switches: up to 10 million operations.
• IP protection degree: Fox is classified IP 65 / IP 66 / IP 67 / IP 69K.
• NEMA protection degree: Fox is classified Type 4X (cULus marked versions).
• Extreme temperature resistance: -40°C to +80°C.
• It features transmission and gear driving shafts made of stainless steel AISI 430F or AISI 303, worm gear transmission shaft rotating on ball bearings, self-lubricating technopolymer gears and driving bushes, technopolymer base and cover.
• All materials and components used are wear resistant and guarantee protection of the unit against water and dust.

OPTIONS

• Revolution ratios from 1:3 to 1:2870, achieved by combining different secondary output stages.
• Snap action switches with 1NO+1NC contacts or slow action switches with 1NC contact.
• It can be equipped with a cam set (with up to 5 switches) and potentiometers, encoders, Yankee absolute encoders.
• Dedicated cable glands or connectors.
• Available with anti-moisture plug fitted to the base by means of a lock nut, improving transpiration while maintaining protection against water.
• Available with flanges, pinion gears and couplings.
• Plates with universal adapters to replace existing systems.

CERTIFICATIONS

• CE marking and cULus* marking.
• Fox is available, upon request, with the SIL1 certification
(Safety Integrity Level 1), according to Standard IEC 61508.
• Complying with accident prevention regulation BGV C 1 (only
for Germany).
• HALT TEST (Highly Accelerated Life Test) passed, simulating
conditions largely exceeding standard operating conditions.

Slip ring collectors designed to transfer AC/DC current from a fixed supply point to a rotating structure,
transmitting power and control signals, both analogue and digital, to mobile units.
Thanks to the high degree of customization, they are used in a variety of industrial sectors, on cranes, rides, packaging plants.

FEATURES
• Suitable for data and control applications.
• They support the major high speed data transmission and industrial bus system protocols.
• High quality materials and components guarantee reliability
and durability.
• IP protection degree: Pegasus are classified up to max. IP 65.

OPTIONS
• High degree of customization thanks to a fully modular construction system.
• Different assemblies available for low voltage.
• On request, they can be equipped with hydraulic couplings.

CERTIFICATIONS
• CE marking.
