planetary gear unit

SEW-EURODRIVE is adding servomotors for high external loads to the MOVI-C® modular automation system. The new CM3C series consists of the sizes 63, 71, 80, and 100. The motors have standstill torques from 2,7 to 40 Nm. This compact range of servomotors with increased inertia are used in machines and applications where a low ratio of load moment of inertia to motor moment of inertia is desired for control reasons. In addition, there is an extensive range of possible options, such as brakes, a large number of different encoder systems and encoder interfaces, as well as flexible motor connection variants for adapting perfectly to the respective conditions of the customer application. The new series is also optionally available with single-cable technology using the newly developed, SEW-EURODRIVE-internal MOVILINK® DDI encoder interface, making wide-ranging digital integration possible. For example, an automatic startup is performed when motors are connected to SEW-EURODRIVE inverters. The encoder signals are transmitted digitally and the brake control system is also digital, with an option for monitoring the condition of the brake. To provide customers with the greatest possible degree of flexibility in their system, the CM3C motor will be offered in future both with standard SEW-EURODRIVE encoder systems and also with DRIVE-CLiQ, EnDat 2.2, and HIPERFACE DSL® encoders. As is usual for SEW-EURODRIVE, the motor series offers a diverse range of options. When combined with the Bruchsal-based company's modular gear unit system, the possibilities are almost endless. One key unique selling point is the availability of two brake versions. Alongside the 24 V holding brake typical for servomotors, there is also a brake with increased working capacity for applications where service braking or emergency braking is required. In combination with the single-cable technology, there is also a new smart brake rectifier for the brake's AC connection. This is current-controlled and can cope with a wide range of input voltages from 100 to 500 V. Typical areas of application include machine automation, handling gantries, and trolley drives.

Sizes: 63, 71, 80, 100, each in the lengths S, M, and L

Rotational speeds: 2000, 3000, 4500, and 6000 min-1

Torque M0: 2.7 to 39.6 Nm

Maximum torque: 8.1 to 118.8 Nm

Inertia:1.54 to 99.5 kg/cm²

Do you want to save time while also gaining flexibility? Now this is possible – with our MOVITRAC® advanced standard inverter. The unit can be used in a wide variety of areas of application thanks to its power range from 0.25 to 315 kW, as well as a comprehensive and scalable function package.
If you need a compact inverter that makes your work easier, but at the same time gives you openness with regard to control systems, our MOVITRAC® advanced standard inverter is the right choice.Designed and developed as a compact all-rounder, the MOVITRAC® advanced can control and monitor both synchronous and asynchronous AC motors with or without encoders, as well as asynchronous motors with LSPM technology or synchronous and asynchronous linear motors. It has a wide power range from 0.25 to 315 kW and an overload capacity of 150%.The MOVITRAC® advanced offers flexibilitythanks to its integrated communication interface which allows connection to commonly used control systems. It can be connected via PROFINET, EtherNet/IPTM, EtherCAT®/SBusPLUS, Modus TCP, EtherCAT® CiA402 or POWERLINK CiA402. You can also configure the functional safety with MOVITRAC® advanced – from the integrated safety function STO to higher-level safety functions and safe communication.The MOVITRAC® advanced is ideal for conveying and motion applications such as conveyor belts, hoists or palletizers – a truly compact all-rounder.

The new performance class progressive from the controller portfolio supplements the automation module set MOVI-C®. This high-performance, scalable motion and logic control solution makes it easy for mechanical and plant engineers to automate a whole range of applications. Three key market requirements for machine and system automation are met – scalability, smart technology and connectivity.

The MOVI-C CONTROLLER progressive is based on the new CPC (Cyber Physical Controller) modular system, which features numerous hardware components such as scalable CPU modules, fieldbus options (multi-protocol capability) and Wi-Fi variants. The passive cooling and RTC (Real Time Clock) function without battery replacement make 100% maintenance-free operation possible. The modular software system includes MOVIKIT® software modules, which meet every possible requirement in terms of motion control and real-time control, and solutions for safety, axis/controller replacement functions and configured code generation. By systematically implementing a software layer model based on Hypervisor technology, the new generation of controllers clearly sets itself apart from existing controller concepts on the market. This offers a simple means of enabling non-reactive interaction between the real-time controller on the one hand and, on the other, higher-level software functions such as visualization, condition monitoring, data mining, engineering software, diagnostics, IT communication stacks and intelligent sensors. A CFast memory card that supports extremely fast access to data enables the famously easy device replacement. The card contains all important data such as firmware, application, axis data sets and application data.

Due to its slimline design, the controller is also ideal for tight installation spaces . It can just as easily be used for modular machine modules as for coordinated tasks in a line network. Thanks to a cutting-edge software structure, the operating system is available separately and independently for engineering, programming, diagnostics and visualization. Version incompatibility issues between the individual programs are also a thing of the past. This solution enables simple operation and web visualization. HMI or OPC-UA enable visualization and external communication. The trend for hardware-independent solutions for machines is thus supported

Hardware designs: 1-core, 2-core, 4-core

4-core design feature: Real time (IEC Runtime) + Windows 10 IoT optional

Programming: CoDeSys 3, IEC61131-3

Fieldbus master: EtherCAT®/SBusPLUS

Fieldbus slave: EtherNet/IPTM, PROFINET IO, Modbus TCP, OPC UA

Within the modular automation module set MOVI-C® the mechatronic drive unit MOVIGEAR® performance is the first product for decentralized installation, consisting of parallel-shaft helical gear unit, permanent magnet motor and integrated drive electronics in a single housing.

MOVIGEAR® performance with direct fieldbus connection is intended especially for the area of dynamic materials handling technology and speed-controlled axes up to positioning tasks. Communication takes place via fieldbus interfaces, such as PROFINET IO, EtherNet/IP™ and Modbus TCP, and the integrated digital inputs and outputs.

The new drive unit is characterized by its compact design and high overload capacity. By achieving the highest motor efficiency class IE5 according to IEC TS 60034-30-2 and maximum system efficiency in accordance withto IEC 61800-9-2, MOVIGEAR® performance surpasses all conventional solutions to date.

These new products expand the possible applications of SEW‑EURODRIVE's decentralized drive technology, which has proven itself an asset over the decades. To combine its benefits with those of the MOVI‑C® modular automation system, the decentralized drive systems have been developed on the basis of the MOVI‑C® portfolio. They complement the products released so far in terms of functionality and consistency.

Typical areas of application for the new product portfolio include the food and beverage industry, intralogistics and parcel logistics, and also the automotive industry and airports.

Performance classes: 0.8 KW / 1.5 kW / 2.1 kW

Torque classes: 200 Nm / 400 Nm

Overload capacity: 300% for 5 s

Ambient temperature: -25 °C to +40 °C (+60 °C)

Degree of protection: IP65 according to EN 60529

Communication: PROFINET IO, EtherNet/IPTM, Modbus TCP, POWERLINK, EtherCAT®/SBusPLUS, AS-Interface, Binary Control,

Safety functions: Safe Torque Off (PL e) integrated

Encoder: Integrated multi-turn absolute encoder

SEW-EURODRIVE is adding servomotors for high external loads to the MOVI-C® modular automation system. The new CM3C series consists of the sizes 63, 71, 80, and 100. The motors have standstill torques from 2,7 to 40 Nm. This compact range of servomotors with increased inertia are used in machines and applications where a low ratio of load moment of inertia to motor moment of inertia is desired for control reasons. In addition, there is an extensive range of possible options, such as brakes, a large number of different encoder systems and encoder interfaces, as well as flexible motor connection variants for adapting perfectly to the respective conditions of the customer application. The new series is also optionally available with single-cable technology using the newly developed, SEW-EURODRIVE-internal MOVILINK® DDI encoder interface, making wide-ranging digital integration possible. For example, an automatic startup is performed when motors are connected to SEW-EURODRIVE inverters. The encoder signals are transmitted digitally and the brake control system is also digital, with an option for monitoring the condition of the brake. To provide customers with the greatest possible degree of flexibility in their system, the CM3C motor will be offered in future both with standard SEW-EURODRIVE encoder systems and also with DRIVE-CLiQ, EnDat 2.2, and HIPERFACE DSL® encoders. As is usual for SEW-EURODRIVE, the motor series offers a diverse range of options. When combined with the Bruchsal-based company's modular gear unit system, the possibilities are almost endless. One key unique selling point is the availability of two brake versions. Alongside the 24 V holding brake typical for servomotors, there is also a brake with increased working capacity for applications where service braking or emergency braking is required. In combination with the single-cable technology, there is also a new smart brake rectifier for the brake's AC connection. This is current-controlled and can cope with a wide range of input voltages from 100 to 500 V. Typical areas of application include machine automation, handling gantries, and trolley drives.

Sizes: 63, 71, 80, 100, each in the lengths S, M, and L

Rotational speeds: 2000, 3000, 4500, and 6000 min-1

Torque M0: 2.7 to 39.6 Nm

Maximum torque: 8.1 to 118.8 Nm

Inertia:1.54 to 99.5 kg/cm²

Do you want to save time while also gaining flexibility? Now this is possible – with our MOVITRAC® advanced standard inverter. The unit can be used in a wide variety of areas of application thanks to its power range from 0.25 to 315 kW, as well as a comprehensive and scalable function package.
If you need a compact inverter that makes your work easier, but at the same time gives you openness with regard to control systems, our MOVITRAC® advanced standard inverter is the right choice.Designed and developed as a compact all-rounder, the MOVITRAC® advanced can control and monitor both synchronous and asynchronous AC motors with or without encoders, as well as asynchronous motors with LSPM technology or synchronous and asynchronous linear motors. It has a wide power range from 0.25 to 315 kW and an overload capacity of 150%.The MOVITRAC® advanced offers flexibilitythanks to its integrated communication interface which allows connection to commonly used control systems. It can be connected via PROFINET, EtherNet/IPTM, EtherCAT®/SBusPLUS, Modus TCP, EtherCAT® CiA402 or POWERLINK CiA402. You can also configure the functional safety with MOVITRAC® advanced – from the integrated safety function STO to higher-level safety functions and safe communication.The MOVITRAC® advanced is ideal for conveying and motion applications such as conveyor belts, hoists or palletizers – a truly compact all-rounder.

The new performance class progressive from the controller portfolio supplements the automation module set MOVI-C®. This high-performance, scalable motion and logic control solution makes it easy for mechanical and plant engineers to automate a whole range of applications. Three key market requirements for machine and system automation are met – scalability, smart technology and connectivity.

The MOVI-C CONTROLLER progressive is based on the new CPC (Cyber Physical Controller) modular system, which features numerous hardware components such as scalable CPU modules, fieldbus options (multi-protocol capability) and Wi-Fi variants. The passive cooling and RTC (Real Time Clock) function without battery replacement make 100% maintenance-free operation possible. The modular software system includes MOVIKIT® software modules, which meet every possible requirement in terms of motion control and real-time control, and solutions for safety, axis/controller replacement functions and configured code generation. By systematically implementing a software layer model based on Hypervisor technology, the new generation of controllers clearly sets itself apart from existing controller concepts on the market. This offers a simple means of enabling non-reactive interaction between the real-time controller on the one hand and, on the other, higher-level software functions such as visualization, condition monitoring, data mining, engineering software, diagnostics, IT communication stacks and intelligent sensors. A CFast memory card that supports extremely fast access to data enables the famously easy device replacement. The card contains all important data such as firmware, application, axis data sets and application data.

Due to its slimline design, the controller is also ideal for tight installation spaces . It can just as easily be used for modular machine modules as for coordinated tasks in a line network. Thanks to a cutting-edge software structure, the operating system is available separately and independently for engineering, programming, diagnostics and visualization. Version incompatibility issues between the individual programs are also a thing of the past. This solution enables simple operation and web visualization. HMI or OPC-UA enable visualization and external communication. The trend for hardware-independent solutions for machines is thus supported

Hardware designs: 1-core, 2-core, 4-core

4-core design feature: Real time (IEC Runtime) + Windows 10 IoT optional

Programming: CoDeSys 3, IEC61131-3

Fieldbus master: EtherCAT®/SBusPLUS

Fieldbus slave: EtherNet/IPTM, PROFINET IO, Modbus TCP, OPC UA
