AC Servo System - SANMOTION G

This is a brand new compact, lightweight, and energy-efficient AC servo system with evolved servo performance. This servo system provides high-speed and high-precision control of equipment, greatly improving the productivity and processing quality. It has various safety functions to ensure the safety of operators, such as monitoring of power supply status and communication quality, estimation of the remaining life of the holding brake, and prevention of electronic component failures.

FeaturesSpeed Frequency Response

With newly developed current control, speed frequency response has been increased to 3.5 kHz (1.6 times higher than our conventional product*) This helps improve the processing quality of machinery.

The Positioning Settling Time

By accurately detecting and compensating for Coulomb friction, viscous friction, and the force of gravity, the positioning settling time has been shortened 5.5 ms, which is 1/3 that of our conventional product.*

Extended output range at high speeds

The servo motor's maximum speed has been increased from 6000 min-1 to 6500 min-1 compared to our conventional product.*
A combination of a new PWM control and the faster motor speed has expanded the motor output range, speeding up the system without using a larger motor.
Moreover, the motor has low cogging effect and low heat generation.

The High-Resolution Encoder

This product comes with a 23-bit encoder as standard (64 times that of our conventional model*), and even an encoder with a maximum of 27-bit high resolution can be selected as an option. The high-resolution encoder enables high-precision, stable positioning.

Improved Reliability and Maintainability

Failure of holding brake and electronic components can be prevented by predicting the remaining life of the holding brake, in systems where braking is needed, and by optimally controlling the inrush current limiting circuit.

The monitoring of the main circuit input voltage and the detection of overvoltage in the control circuit power supply can be performed. Early identification of faults can help shorten system downtime.
The quality of encoder and EtherCAT communication can be diagnosed. The impact on communication quality due to noise and installation environments can be monitored, contributing to improving the environmental durability of the system.

Usable in Various Environments

The vibration resistance of the servo motor and amplifier has been improved two-fold and 20%, respectively, compared to the conventional products.*
The operating temperature range of the servo amplifier has been extended by approximately 10%, covering from 0 to +60˚C. This allows the amplifier to be used at a high altitude of 2000 m above sea level.
With improved environmental durability, this product can be used in a variety of regions and environments.

Compact, Lightweight, and Energy-saving

Compared to the conventional products,* the motor and amplifier have been made lighter by up to 28% and 5%, respectively, and the overall motor length has been shortened by up to 22%.
Furthermore, the energy loss of the motor and amplifier has been reduced by up to 8% and 22%, respectively, and brake power consumption has been reduced by up to 44%.
This greatly contributes to the downsizing, weight reduction, and energy savings of your equipment.

Easy and User-friendly

A single cable can connect both the motor power and brake connections and the connector orientation can be changed for easy wiring.
This product can measure the frequency characteristics of equipment with high precision and optimize servo parameters automatically, making start-up easy.
Both the servo motor and servo amplifier are designed to be compatible with the conventional products* for easy replacement.

2 Phase Stepping Systems

With high torque, low vibration, low noise, and high resolution. Their rich lineup is used in a wide range of fields.

Rich lineup
0.9°step angle type
The high resolution model realizes a dramatic reduction of vibration and noise by changing the basic step angle from 1.8°to 0.9°(Approximately 80% reduction in vibration at 42 mm sq.). Enables smooth driving and accurate positioning.

Thin type
This high-performance thin stepping motor effectively uses device space. Depending on the torque required, four motor lengths can be selected.

14 mm compact type
The flange size and weight are both the smallest in the industry*1, at 14 mm and 28 g, respectively. Though small, it maximizes torque, and positioning can be performed with high accuracy. Two types of output shaft are available: single-shaft and dual-shaft.

*1 As of March 1, 2017.

Strong support for product development with abundant technical knowledge and know-how
The SANMOTION F2 series offers a wide variety of models that can be selected to meet the needs of the application. In addition, motors can be customized according to customer needs, such as with hollow shafts, connectors, or adapted for use in vacuum environments.

DC Servo Motor - SANMOTION K

The SANMOTION K DC servo motors achieve smooth operation, high efficiency, and low noise.
These motors are suitable for applications requiring high precision, including precision measuring instruments and medical equipment.

High accuracy (Smooth operation)Cogging torque has been reduced by up to half compared with our conventional DC servo motors.*
This enables smooth motor operation even at low speeds, improving the accuracy of equipment movements.Energy-saving (High efficiency)Power loss has been reduced by up to approximately 30% and efficiency has been increased by 10% compared with our conventional DC servo motors.*
This reduces heat generation within equipment and contributes to energy savings.Low noiseBrush vibrations have been reduced, and the rigidity of motor parts has been improved.
Compared with our conventional DC servo motors,* noise levels have been reduced by up to 8 dB.Low-voltage models availableIn addition to 75 VDC class models, low-voltage (24 VDC class) models are also available.
The low-voltage models are safe for use in medical equipment and other applications close to people.IP43 protection ratingAll servo motors have a protection rating of IP43.Application examples* Compared with our conventional SANMOTION T DC servo motors.

Splash Proof Fan

Splash Proof Fans can be used in environments exposed to water. They are suitable for cooling PV inverters and other devices installed outdoors.

Water and Dust Resistance for Outdoor Devices
These fans achieve excellent IP68, IP55, or IP54 water and dust protection.

<Lineup>
(a) Splash Proof Fan
40x20mm, 40x28mm, 60x25mm, 80x25mm, 80x38mm, 92x25mm, 92x38mm, 120x38mm,
140x38mm, 140x51mm, Φ172x51mm

(b) Splash Proof ACDC Fan
Φ172x51mm

(c) Splash Proof Centrifugal Fan
Φ100x25mm, Φ133x91mm, Φ150x35mm, Φ175x69mm, Φ221x71mm, Φ225x99mm

(d) ACDC Splash Proof Centrifugal Fan
Φ190x88mm, Φ225x99mm, , Φ250x99mm

(e) Splash Proof Blower
97x33mm

These fans also have long expected lives of up to 180,000 hours without maintenance.
(When continuously operated in free air at 60˚C, rated voltage, indoors.)
They demonstrates excellent durability even in harsh environments.

For PWM control compatible models, remote control of fan speed in response to device conditions is possible. This realizes reduced power consumption and noise level.

We also have models with various sensors available including a pulse sensor for detecting fan speed and locked-rotor sensor for detecting the rotation stop of a fan.

* Availability of sensors varies by model. Contact us for details.
