IO-Link Valve Connector Innovation

PNEUMATICS
Form A and Form B Industry - IO-Link CLASS A

Upgrading your actuators – Smart Connector is the easiest way to add monitoring and diagnostic functions to existing solenoid coils and valves for a wide range of pneumatic applications.

HYDRAULICS
Form A - IO-Link CLASS B

Increased power – allowing to operate hydraulic coils or valves with higher power consumption.

According to the digitization of the "last meters" in the automation technology, nass magnet as an expert for pneumatic valve actuators presents the innovative valve driver with IO-Link interface, implemented in a DIN interface connector.

Connected valves can be remotely controlled and monitored via the network using this peer to peer interface.

Useing with a master, diagnostic data for the connector, solenoid coil and valve system can be retrieved, monitored and connected to cloud-based systems.

For the use in extreme environmental conditions nass magnet also offers robust versions in the protection classes IP65/IP67.

• IO-Link interface
• DIN norm interface valve connector
• Quick and easy connection
• Status monitoring, RGB LED
• Power saving with PWM mode
• Parameterization through software
• Double switching cycle counter
• Diagnostic data
• Event messages
• Data storage
• Off-line mode
  pre-programmed timer and/or PWM

Visit the product page: https://www.nassmagnet.com/nmsc

The valve connectors from nass magnet comply with the CECC/EN 175301-803 standard and are available both free-assembly and with molded cable, in designs A, B, B-Industrial, C and Micro.

Plug-in solutions can be implemented easily and quickly with the modular international circular connector system according to IEC 61076-2.

M12 connectors are currently recommended as field bus connectors for almost all field bus specifications and are available in multiple codings.

The introduction of the new M8/M12 connectors illustrates nass magnet commitment to develop a reliable and flexible I/O or field bus connection on the circuit board.

According to the digitization of the "last meters" in the automation technology, nass magnet as an expert for pneumatic valve actuators presents the innovative valve driver with IO-Link interface, implemented in a DIN interface connector.

Connected valves can be remotely controlled and monitored via the network using this peer to peer interface.

Useing with a master, diagnostic data for the connector, solenoid coil and valve system can be retrieved, monitored and connected to cloud-based systems.

For the use in extreme environmental conditions nass magnet also offers robust versions in the protection classes IP65/IP67.

• IO-Link V1.1.3 compatible Master
• Ethernet/TCP-IP interface,
• DHCP or static IP address configuration
• Standardized JSON mapping
• Node-RED integration supported
• 4 independent powered IO-Link Class A ports
• IP67 Protection
• MQTT supported

IO-Link V 1.1.3. fully backward IO-Link compatibility

Ethernet/TCP-IP interface, which is globally accepted and highly supported, making it easy to integrate with existing systems or to build a new system.

Visit the product page https://www.nassmagnet.com/nmetm
