SV670 – Single-Axis Servo Drive

• 1/3 ph 200V, 3 ph 400V
• 1 kW to 7.5 kW
• STO SIL 3 PL e
• Ultra-fast 4.5 kHz current loop
• Easy set-up and tuning
• Feedback encoder interface: serial (Weton), Nikon and Tamagawa
• Second encoder interface: incremental quadrature
• EtherCAT, pulse, CANopen variants
• +24 VDC backup control supply (as variant)

SV680 – Single-Axis Servo Drive

• 1/3 ph 200V, 3 ph 400V
• 1 kW to 7.5 kW
• STO SIL 3 PL e
• SS1, SS2, SLS, SBC, SOS, SSM, SDI SIL 3 PL e (option)
• Ultra-fast 4.5 kHz current loop
• Easy set-up and tuning
• Feedback encoder interface: serial (Weton), BiSS-C and SSI
• Second encoder interface: incremental quadrature, serial (Weton), BiSS-C and SSI
• EtherCAT and pulse variants
• Linear motor control
• +24 VDC backup control supply (option)

Easy series PLC

• Compact footprint
• Able to control up to 32 EtherCAT axes (72 slaves)
• Up to 16 local expansion modules (GL20)
• Built-in I/Os
• 8 High speed inputs (200 kHz)
• 8 DO (with 4x 200 kHz channels & PWM support)
• PLCopen-compliant axis control
• Axis group for lineal and circular interpolation, CAM table functionality
• Simulation mode for offline debugging
• Supports function block and function for encapsulation, code reusability, and scalability
• ST, LD, SFC language support
• Multiple communication protocols: Modbus RTU/TCP, CANopen (optional), Ethernet/IP (scanner)

GL20 Expansion modules

• Local & remote I/O expansion for Easy series, remote for AC700, AC800, H5U & AM600
• EtherCAT, PROFINET, Ethernet/IP and I/O-Link couplers for remote expansion (up to 16 modules)
• Min EtherCAT cycle 125µs
• DI/DO hardware response time within 100µs
• AI/AO capture cycle up to 62.5 µs
• Digital I/O modules
• Analog I/O modules
• Temperature sensing modules

• CPU: Celeron series (AC703) or Intel i5 (AC810)
• Dual EtherCAT ports with redundancy support (AC802, AC810)
• Up to 256 EtherCAT axes
• Multiple communication protocols:
  • Modbus RTU/TCP
  • Ethernet IP
  • OPC UA
• Remote commissioning and IIoT capabilities
• IEC 61131-3 programming environment (CODESYS)
• Webvisu functionality (AC703, AC810)

MD800 is answering the call of OEMs for reduced installation costs and smaller machine cabinets. It has a modular design that allows up to 8 drives per rectifier, reducing overall drive footprint by up to 50% compared to traditional single drive modules. And it’s the rising star of our product range.

• 50% footprint reduction
• Common rectifier, 1 to 8 drives
• Single and dual drive modules
• 1 ph 200V, 3 ph 400V
• 2 kW to 7.5 kW (dual: up to 3.7 kW)
• STO SIL 3 PL e individual for each drive
• +24 VDC backup control supply
• Induction and PMS motor control (sensorless)
• Built-in Modbus RTU, CANopen
• EtherCAT, PROFINET, Ethernet/IP as option
