The mild steel single-door modular floor standing enclosure range, MCS, with a IP 55 protection degree, is available off the shelf in many different sizes. This enclosure range is well-suited for many different applications. The risk for component failure, and with that unnecessary downtime, is eliminated as water and dust are prevented from entering the enclosure.

Features & Benefits

• Frame: Seam welded reversed open profiles with 25 mm hole pattern, according to DIN 43660 Including integrated external hole pattern
• Door: Mounted with four hinges allowing left or right hand opening; including door frame with 25 mm hole pattern
• Rear panel: Fitted by M6 torx screws; standard facilities for rear door mounting
• Side Panels supplied as an accessory
• Removable roof panel
• Lock: Espagnolette 4-point locking system which does not interfere with the enclosure inner space; standard double-bit lock with 3 mm insert

• Bottom plate: Consists of three or four (D>600) pieces
• Mounting plate: Double folded and adjustable in depth by steps of 25 mm, with the MPD02 (supplied as an accessory)
• Earthing/Grounding: All panels are earthed through their fittings and are equipped with a separate earthing stud
• Mounting requirements: Standard delivery ready for combined installation; for stand-alone installation add side panels
• Delivery: Frame with fitted door, rear panel, roof panel, bottom plates, mounting plate (not included for PER5 version) and door frame; for 400 mm wide enclosures, a mounting plate, bottom plates and door frame are not included; for enclosures 2200 mm height, delivery includes two CMB profiles mounted in depth; delivery also includes earthing bolts
