By using split cable glands by icotek pre-terminated cables with diameters from 1 to 35 mm can be quickly routed into enclosures, control panels or machines and be sealed with up to IP66 / IP68 / UL Type 4X rated ingress protection (certified according to EN 60529 / UL50-E). In addition, the cable glands serve as strain reliefs on the cable. The split cable glands enable quick and easy assembly which is great for retrofits and maintenance.

With the membrane based cable entry plates cables, pneumatic and hydraulic hoses or optical fibres can be quickly and space-savingly routed into control cabinets, panels or machines and be sealed with certified protection class up to IP68 (acc. to EN 60529) and UL Type 4X (acc. to UL50 E). icotek cable entry plates are cost, space and time saving alternatives to traditional cable glands.

For process measurement and control equipment an increasingly higher level of protection against failure is required. EMI shielding and earthing is very important. The area where the cable shield is connected to the cabinet earth is a critical point. It is very important that the connection has a low resistance. All icotek EMC cable clamps for shielding cable diameters from 1.5 to 75 mm have been tested utilising various frequency ranges and in all tests there was minimal leakage resistance.

In case of conducted as well as field bound EMI disturbances, our split cable entry system EMC-KEL-DS and our split cable gland EMC-KVT-DS offer an effective way to divert and block those disturbances and provides an alternative to conventional EMC cable glands — especially when routing cables with connectors.

Using the patented grommet based icotek cable entry system, a large number of pre-terminated cables (up to 65 mm in diameter) and cables without connectors (up to 75 mm in diameter) can be quickly routed into enclosures, control panels or machines and be sealed with up to IP66 / UL type 4X rated ingress protection (certified according to EN 60529 / UL50-E). In addition, the cable entry frames serve as strain reliefs on the cable (acc. to EN 62444). The split cable entry system enables quick and easy assembly which is great for retrofits and maintenance.

By using split cable glands by icotek pre-terminated cables with diameters from 1 to 35 mm can be quickly routed into enclosures, control panels or machines and be sealed with up to IP66 / IP68 / UL Type 4X rated ingress protection (certified according to EN 60529 / UL50-E). In addition, the cable glands serve as strain reliefs on the cable. The split cable glands enable quick and easy assembly which is great for retrofits and maintenance.

With the membrane based cable entry plates cables, pneumatic and hydraulic hoses or optical fibres can be quickly and space-savingly routed into control cabinets, panels or machines and be sealed with certified protection class up to IP68 (acc. to EN 60529) and UL Type 4X (acc. to UL50 E). icotek cable entry plates are cost, space and time saving alternatives to traditional cable glands.

For process measurement and control equipment an increasingly higher level of protection against failure is required. EMI shielding and earthing is very important. The area where the cable shield is connected to the cabinet earth is a critical point. It is very important that the connection has a low resistance. All icotek EMC cable clamps for shielding cable diameters from 1.5 to 75 mm have been tested utilising various frequency ranges and in all tests there was minimal leakage resistance.

In case of conducted as well as field bound EMI disturbances, our split cable entry system EMC-KEL-DS and our split cable gland EMC-KVT-DS offer an effective way to divert and block those disturbances and provides an alternative to conventional EMC cable glands — especially when routing cables with connectors.
