ibaDatCoordinator

As a central part of the iba system, ibaPDA has been proven to be one of the most versatile systems acquiring high-resolution process data. The comprehensive connectivity to the process with the autodetect function for easy configuration, the client-server architecture and the variable recording options are just some of the convincing features.

ibaPDA at a Glance

• System with comprehensive connectivity for acquiring high-resolution process data
• Efficient acquisition of data from control systems of different manufacturers and device generations
• Triggered or time-based data storage in measurement files or in ibaHD-Server
• Several data recordings possible at the same time
• Additional data storage types and output interfaces for transferring data outside the iba system
• Acquisition of descriptive additional information via text signals
• Individually configurable live displays with client-server architecture › Internal processing and monitoring of signals and output of current messages and alarms
• Use of data by maintenance, production, quality assurance, technology, data analysts and much more

ibaHD-Server allows you to continuously save data acquired with ibaPDA. Find events from the past with a mouse click, navigate and zoom quickly from the year, month or week view into the milliseconds range. Use ibaHD-Server to analyze your data over a long period of time and to automatically create day, shift or monthly reports.

ibaHD-Server at a Glance

• Continuous recording of measured data and events over a long time period
• Simultaneous recording from several ibaPDA systems and import of measurement files
• Direct access to historical data with intuitive use for visualization, such as scrolling, jumping to a date
• Quick zoom function from the annual, monthly or weekly overview down to the range of milliseconds
• Display and filtering of historical events and joint visualization with measurement data
• Long term analysis of historical data with ibaAnalyzer and ibaDaVIS
• Automatic calculation of KPIs and automatic reporting with ibaDatCoordinator and ibaAnalyzer
• API for access to historical data from 3rd party applications

ibaAnalyzer is characterized by broad functionalities for analyzing and evaluating. The application offers an intuitive operation along with the complex scope of functions. The license for editing measurement files which have been generated with the iba system, is for free.

ibaAnalyzer at a Glance

• Comprehensive offine analysis
• Intuitive user interface with smart docking windows and drag & drop function
• Combination of data coming from various measurement processes or data sources
• Powerful mathematical and technological functions for manipulating, combining, calculating and generating signals
• Powerful graphical digital fiter designer
• Analyzing in the frequency range (FFT)
• Reuse of analyses
• Versatile markers for measurement of signals
• Macro functions for protecting know-how

With the ibaMAQS modular system, iba has raised the bar in the field of measurement technology. This flexible system enables user-specific solutions and is both scalable and perfectly tuned for demanding tasks.

ibaMAQS at a Glance

• Modular system for the acquisition and processing of measurement signals
• Acquisition of different data types, such as sensor, machine, vibration, energy data, etc.
• Decentralized, local and synchronous data acquisition
• High-precision synchronization with ibaNet
• Suitable for direct acquisition from machines
• Quick module change, DIN-rail mounting
• In the final state, a wide range of modules can be combined as required
• Data transfer over Ethernet with standard network components
