Functional Safety

We are the leading provider of development services in the area functional safety covering measurement, drive, and control technology, medical engineering, for the associated control devices and for components of collaborative robot systems. embeX was the first company worldwide to be awarded the highest maturity level for Functional Safety Management (FSM) according to IEC 61508 by TÜV Rheinland.

embeX develops embedded systems ranging from SIL 1 to SIL 4, from PL a to PL e, from medical device class I to III. We advise and support our customers in all issues relating to functional safety, when implementing a functional safety management system and during assessment and certification.

Our safety experts actively work in the safety standardisation groups such as IEC 61508 (SIL) and maintain constant contact with all renowned notified bodies.

Engineering Services

• Competent and comprehensive consulting
• Safety-related development projects with proof of conformity
• Definition and implementation of a lean development process for safety-related products
• Specification of safety requirements
• Definition of safety concepts
• Development of self-test libraries (STL) for ARM® based controllers up to SIL 3
• Standard-compliant verification and validation
• Risk and failure analysis (FMEA, FMEDA, FTA) from system level down to component level
• Calculation of safety parameters, such as PFH, PFD, SFF, MTTFd
• Design and dimensioning of safety relevant mechanical components
• Admission and certification: We produce the documents you need and represent you in dealing with the notified bodies

Technologies

• Safety Concepts
  • Analysis of potential hardware faults
  • Selection of suitable hardware architectures
  • Qualification of sensor technologies for safety applicationsDealing with non-safe software components (SOUP, COTS, legacy software)
  • Safe operation and parametrisation
• Functionally Safe Hardware - Architectures
  • Single-fault safety, Category 2 according to ISO 13849, HFT 0 according to IEC 61508
  • Two-fault safety, Categories 3 and 4 according to ISO 13849, HFT 1 according to IEC 61508
  • Initial fault tolerance according to EN 60601-1
  • Risk and failure analysis (FMEA, FMEDA, FTA) from system level down to component level
• Functionally Safe Software, Self-Test Libraries (STL)
  • For ARM® based controllers up to SIL 3 high demand
    • Certified libraries available
    • Reference: Self-test library offered by Microchip
    • Further developments on request
• Functionally Safe Drive Systems
  • Safety functions for drives like STO, SBC, SS1, SLP, SLS and SLT
  • Active run to safe position using energy storage systems
  • Collaborative robot systems
• Safety & Security
  • Since according to IEC 61508-1 and the IEC TR 63074, a threat analysis must be carried out in case of foreseeable threats to IT security in order to determine the requirements for IT security, we also support our customers in all fields of security and the combination of safety and security.
• Functionally Safe Communication
  • Frequently implemented safe interfaces are:CANopen Safety, CIP Safety, FSoE, OPC UA Safety, IO-Link Safety, open Safety, PROFIsafe
